Viber / Zalo: Hotline: 092 888 2345Camera IP Panasonic K-EF114L08
• Smart look Day/Night Fixed Dome Camera with IR illuminator
• High resolution: 600 TV lines
• High sensitivity with Day/Night function: 0.6 lux(Color), 0 lux (B/W, IR LED is ON)
• Digital Noise Reduction
• 3.6 mm fixed focal lens
• Wide Coverage: Horizontal: 76º, Vertical: 57º
| Camera | Image Sensor | 1/3 type interline transfer CCD |
| Effective Pixels | 976 (H) x 582 (V) | |
| Scanning Mode | 2:1 interlace | |
| Scanning Area | 4.8 mm (H) x 3.6 mm (V) | |
| Scanning frequency | Horizontal: 15.625 kHz, Vertical:50.00 Hz | |
| Horizontal Resolution | 600 TV lines | |
| Minimum Illumination | Color: 0.6 lx, B/W: 0 lx (IR LED is ON) at F1.6 | |
| IR LED Light | Auto | |
| IR LED irradiation distance | 20 m | |
| Signal-to-Noise Ratio | > 48 dB | |
| White Balance | ATW, Anti Color Rolling, Manual | |
| Light Control | ELC | |
| AGC | ON/OFF | |
| Electronic Shutter | Auto, 1/50, 1/100, 1/250, 1/500, 1/1,000, 1/2,000, 1/4,000, 1/10,000 | |
| Day Night | Auto / B/W / Color | |
| Digital Noise Reduction | Auto | |
| Back Light Compensation | ON/OFF | |
| Adaptive Tone-Curve Reproduction | ON (Luminance:3steps, Contrast:5steps) / OFF | |
| Privacy Zone | up to 4 Zones | |
| Camera Title | up to 52 alphanumeric characters (26x2) | |
| Mirror image | ON / OFF | |
| Synchronization | Internal | |
| Lens | Focal Length | 3.6 mm |
| Angular Field of View | H: 76°, V: 57° | |
| Input/Output | Video Output | 1.0 V [P-P] / 75 Ω, PAL composite videosignal (BNC) |
| General | Setup Method | OSD setup menu |
| Language | English, Russian, German, French, Spanish, Portuguese, Chinese, Japanese | |
| Safety/EMC Standard | CE (EN61000-6-3, EN50130-4, EN61000-3-2, EN61000-3-3) FCC (CFR 47 PART 15) | |
| Power Source and Power Consumption | 12 V DC, 6W | |
| Ambient Operating Temperature | –10 °C ~ +50 °C (14 °F~ 122 °F) | |
| Ambient Operating Humidity | 85 % or less (without condensation) | |
| Water and Dust Resistance | IP66 | |
| Dimensions | ø110.5 mm x 77.7 mm (H) | |
| Gross Weight (approx.) | 0.4 kg | |
| External Case | Aluminum Alloy |
